[WIN]PathWave Electrical Performance Scan (EP-Scan) (高效信号分析软件) 2023 Update 1

WIN软件7个月前发布 17600879176
42 0 0

[WIN]PathWave Electrical Performance Scan (EP-Scan) (高效信号分析软件) 2023 Update 1插图

Keysight 是德科技的 PathWave Electrical Performance Scan (EP-Scan)是一款可独立运行的 EM 电磁信号仿真软件,仿真结果包括信号完整性度量方面的信息,如通道回波损耗、插入损耗和阻抗时域反射计(TDR)。EP-Scan 可以自动化进行不同设计版本之间的性能比较,并生成仿真报告。

EP-Scan 仅需PCB的布局几何和PCB叠层信息即可运行,不需要器件的IBIS模型或者S参数模型,导入PCB数据后指定要检查的网络和对应的规范标准之后,即可通过“EP-Scan”自动扫描您的PCB设计并生成合规结果报告。

[WIN]PathWave Electrical Performance Scan (EP-Scan) (高效信号分析软件) 2023 Update 1插图1

EP-Scan是执行高效信号完整性分析的理想软件,其重点是以最少的精力和时间捕捉设计中的信号完整性问题。

使用EP-Scan,在导入PCB设计数据后,仅需三个简单的步骤即可获得信号完整性洞察力:

  1. 选择要分析的网络。
  2. 设置测试计划(选择网络的规格)。
  3. 运行分析。

如果任何网络违反所选择的规范标准,则会有明确的指示。如下图所示,差分对PCIE_TX4_P和PCIE_TX4_N超出了阻抗规格。阻抗单元的颜色变化指示违规。

[WIN]PathWave Electrical Performance Scan (EP-Scan) (高效信号分析软件) 2023 Update 1插图2

EP-SCAN 仅需一次点击即可生成仿真报告结果,设置仿真并运行分析后,一键生成报告可最大限度地减少创建报告所需的工作量,消除了复制和粘贴数据的需要,见下图所示:

[WIN]PathWave Electrical Performance Scan (EP-Scan) (高效信号分析软件) 2023 Update 1插图3

功能特色

1、面向硬件设计工程师的全新 SI 生产力软件

2、使用 EP-Scan 在几分钟内比较不同设计版本的性能

3、扫描您的 PCB 设计并快速识别性能问题

4、及早发现设计错误,从而缩短上市时间。

5、轻松创建设计过程报告。

6、轻量级应用程序,可接收布局文件并在仿真后生成信号完整性指标。

7、EP-Scan 还包括:

TDR 阻抗图

标准规格检查器

仿真报告生成

8、对所需网络的仿真不仅会产生走线的特性阻抗和延迟,还会产生回波损耗、插入损耗和阻抗时域反射计(TDR)。

9、EP-Scan使工程师能够在多个网络上快速设置仿真,以确认性能并在设计过程的早期发现问题

[WIN]PathWave Electrical Performance Scan (EP-Scan) (高效信号分析软件) 2023 Update 1插图4

PathWave Electrical Performance Scan (EP-Scan) 2023 Update 1 | 851.2 mb
Keysight Technologies, Inc., a leading technology company that delivers advanced design and validation solutions to help accelerate innovation to connect and secure the world, introduces the Electrical Performance Scan (EP-Scan) 2023 Update 1, a new high-speed digital simulation tool that supports rapid signal integrity (SI) analysis for hardware engineers and printed circuit board (PCB) designers.

EP-Scan 2023 Update 1.0 Release Notes

Feature Updates
– Ability to change display units in Options > Settings.
– Ability to change net types by using a dedicated button and the right-click context menu.
– Ability to change the number of decimal points to display in Options > Settings.
– Ability to change the user interface to the light mode in Options > Settings.
– Ability to import and export substrate files (.ltd).
– Ability to import and simulate layout in the IPC-2581 format.
– Added differential pair skew analysis.
– Added frequency-dependent Svensson/Djordjevic loss model.
– Added result for trace skew to report generation.
– Added the link to online documentation.
– Beta features can be enabled in Options > Settings.
– Differential pairs can be made or broken by a dedicated button and the right-click context menu.
– Improvement and correction on the generated simulation report.
– Improvement of EP-Scan project management.
– Improvement on general error reporting and message log.
– Improvement on test plan setup and error reporting.
– Sorting improvement on the Z0 results table.
– Speed improvement when importing test plans with a large number of nets.
– Trace etch angle can be specified in the substrate dialog.

Keysight’s PathWave, an open, scalable, and predictive software platform, offers fast and efficient data processing, sharing and analysis at every stage in the product development workflow. Combining design software, instrument control and application-specific test software, it enables engineers to address increasing design, test, and measurement complexity and develop optimal electronic products.
PathWave High-Speed Digital Applications (HSD Apps) provides signal integrity software to help hardware engineers and printed circuit board designers create high-speed design prototypes, perform validation, and generate performance reports. Each application is lightweight and requires little effort to be productive.
PathWave Electrical Performance Scan (EP-Scan) enables hardware design engineers to import ODB++ layouts and perform preliminary signal integrity analysis quickly. Analysis results include trace impedance, time delay, channel S-parameters, TDR impedance plot. The software checks for violation against standard specification and can generate simulation reports.

Keysight Technologies Inc. is the world’s leading electronic measurement company, transforming today’s measurement experience through innovations in wireless, modular, and software solutions. With its HP and Agilent legacy, Keysight delivers solutions in wireless communications, aerospace and defense and semiconductor markets with world-class platforms, software and consistent measurement science. The company’s nearly 10,500 employees serve customers in more than 100 countries.

Product: PathWave Electrical Performance Scan (EP-Scan)
Version: 2023 Update 1 (1.1.0)
Supported Architectures: x64
Languages Supported: english
System Requirements: Windows & Linux *
Size: 851.2 mb
